PRO-H410M-C/CSM-RF ASUS Pro H410M-C/CSM Micro-ATX Motherboard

PRO-H410M-C/CSM-RF Technical Specifications

ASUS Pro H410M-C/CSM LGA 1200 Micro ATX Motherboard

CPU

• Chipset: Intel H410
• CPU Socket: LGA 1200

Back Panel I/O

• USB: 2 x USB 3.1 / USB 3.2 Gen 1 Type-A, 2 x USB 2.0 Type-A
• Display: 1 x HDMI, 1 x DVI-D, 1 x VGA
• Audio: 3 x 3.5 mm
• Ethernet: 1 x Intel I219V Gigabit
• PS/2: 2 x PS/2, 1 x Serial

Memory

• Memory Slots: 2 x 288-Pin
• Support: DDR4 2133, 2400, 2666, 2800, 2933 MHz
• Maximum Capacity: 64 GB
• Channel Architecture: Dual Channel

Storage Expansion

• SATA: 4 x SATA III
• M.2: 1 x M Key 2242, 2260, 2280 (PCIe/SATA)

Internal I/O

• Expansion Slots: 1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1, 2 x PCIe
• USB Headers: 1 x USB 3.1 / USB 3.2 Gen 1, 2 x USB 2.0
• Cooling: 1 x 4-Pin CPU, 1 x 4-Pin System
• Power Connectors: 1 x 24-Pin, 1 x 8-Pin ATX
• Security: Chassis Intrusion, TPM Module
• Diagnostics: 2-Digit Debug LED, Clear CMOS

BIOS

• ROM: 128 Mb

Audio

• Codec: Realtek ALC887 (7.1-Channel)

Software

• Supported OS: Windows 10 (64-Bit)

Physical

• Form Factor: Micro-ATX
• Dimensions: 9.6 x 8.2″ / 24.4 x 20.8 cm
