FTLF1322P1xTR Finisar Fiber Optic Transceiver Module

FTLF1322P1xTR Technical Specifications

Finisar Transceiver Module

Part Number: FTLF1322P1xTR
Manufacturer: FINISAR
Description: This SFP Optical Transceiver is designed for OC-12 SR-1/STM I-4 and OC-12 IR-1/STM S-4.1 applications.
Applications include SONET OC-12 IR-1 / SDH STM S-4.1, SONET OC-12 SR / SDH STM I-4, SONET OC-3 IR-1 / SDH STM S-1.1, and SONET OC-3 SR / SDH STM I-1.
Connections & Interface: Connector type LC; Interface: 2-Wire.
General Parameters:
Data Rate: 622 Mb/s (Fast Ethernet)
Wavelength: 1260 to 1600 nm
Distance/Reach: 15 km
Output Power: -15 to -8 dBm
Fiber Modes: Single Mode Fiber (SMF)
Form Factor: SFP
Receiver Sensitivity: -28 to -8 dBm
Power Dissipation: 0.7 W (700 mW)
Tx Power: -15 to -8 dBm
Tx/Rx Component: FP(Tx)
Supply Current: 165 to 300 mA
Supply Voltage: 3.3 V
Temperature:
Operating Temperature: -40 to 85 °C
Storage Temperature: -40 to 85 °C.
