E25GSFP28LRX Technical Specifications
Intel SFP28 Transceiver Module
Brand: INTEL
Condition: NEW
Device Type: SFP28 Transceiver Module
Form Factor: Plug-in Module
Connectivity Technology: Wired
Cabling Type: 10GBASE-LR, 25GBASE-LR
Data Link Protocol: 10 Gigabit Ethernet, 25 Gigabit LAN
Data Transfer Rate: 25 Gbps
Optical Wavelength: 1310 nm
Maximum Transfer Distance: 10 km (328 ft)
Features: Vertical Cavity Surface Emitting Laser (VCSEL)
Connector: Duplex LC
Media: Single Mode Fiber (SMF)
Transmitter Type: DFB
Receiver Type: PIN
TX Power: -7 to 2.5 dBm
Receiver Sensitivity: < -12 dBm
Power Budget: 5 dB
Receiver Overload: 2.5 dBm
Power Consumption: ≤ 1.5 W
Extinction Ratio: > 3 dB
Industrial Temperature Range: -40 to 85°C (-40 to 185°F)
Protocols: SFF-8472, SFF-8024, SFF-8431, SFF-8432, CEI-28G-VSR
