C1861W-SRST-C-F/K9-RF Cisco 1861 Integrated Services Router

C1861W-SRST-C-F/K9-RF Technical Specifications

Cisco 1861 Integrated Services Router

PRODUCT: Cisco 1861 Integrated Services Router, Integrated Services Router Series Cisco 1800, Model C1861W. Features include WLAN, 8-user SRST/CME, CUE, 4FXS, 4FXO, 8xPOE, and HWIC slot.
CONFIGURATION: Default configuration supports 8-user Cisco Unified CME or SRST.
MEMORY: DRAM (256 MB Cisco IOS Software); Voice messaging (512 MB).
COMPACT FLASH MEMORY: Cisco IOS Software – 128 MB; Voice messaging – 1 GB; Compact Flash.
ONBOARD ETHERNET PORTS: 1 x 10/100 Fast Ethernet; 8 x 10-/100-Mbps LAN; 1 x 10/100 Ethernet expansion port.
WAN SLOT: 1 x HWIC slot.
WLAN HARDWARE: 802.11b/g with automatic rate selection; RP-TNC connectors for external antennas; antenna diversity; indoor range of 1 Mbps at 320 ft (97.54m); WECA interoperability; default antenna gain of 2.2 dBi.
FXS PORTS: 4 built-in FXS ports.
PSTN INTERFACES: 4 built-in FXO ports.
CONSOLE PORT: 1, supports up to 115.2 kbps.
VOICEMAIL PORTS: 6 ports for voicemail and Automated Attendant.
PoE PORTS: Base unit comprises 8 built-in 10/100 PoE ports.
DIMENSIONS: 66 x 266 x 280 mm (H x W x D).
RACK HEIGHT: 1.5 rack unit (RU).
* Includes default Cisco IOS Software image SP Services K9. * Single 3.5-mm audio port or wave file stored in flash memory.
