640996-B21 Technical Specifications
HP Proliant Bl420c G8 CTO Chassis – No CPU
General Information:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 640996-B21
Product Name: Proliant Bl420c G8 Blade Server
Processor & Chipset:
Processor Type: Intel Xeon E5-2400 Series
64-Bit Computing: Yes
Installed Qty: No CPU
Max Supported Qty: 2
Upgradability: Upgradable
Chipset Type: Intel C600
Memory:
Installed Size: None
Maximum Size: 384 GB
Technology: DDR3 SDRAM
Form Factor: DIMM 240-Pin
Storage & Storage Controller:
Hard Drive: None
Hard Drive Support: HP 1.6TB and 800GB 12G SAS Value Endurance SFF 2.5in SC Enterprise Value SSDs
Storage Controller Type: 1 x Serial Attached SCSI 2 – Integrated – PCI Express 3.0 x8
Controller Interface Type: Serial SATA-600 / SAS 2.0
Storage Controller Name: HP Dynamic Smart Array B320i
Channel Qty: 8
RAID Level: RAID 0, RAID 1, RAID 10
Display & Graphics Controllers:
Graphics Controller Type: Integrated
Graphics Processor: Matrox G200
Resolution Support: 1280 x 1024 (32 bpp), 1920 x 1200 (16 bpp)
HP iLO 4 on System Management Memory
16 MB Flash, 256 MB DDR3 with ECC (112 MB after ECC and Video)
Network & Communication:
Networking: Network Adapter – PCI Express 2.0 x8 – Integrated
Ethernet Ports: 10 Gigabit Ethernet
Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol: SNMP, IPMI 2.0, SMASH CLP
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On LAN (WOL)
Compliant Standards: IEEE 802.1q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ap
Expansions & Connectivity:
Expansion Bays Total: 2 (Total) / 2 (Free) x Hot-Swap – 2.5in SFF
Expansion Slots Total: 2 (Total) / 2 (Free) x Processor
12 (Total) / 12 (Free) x Memory – DIMM 240-Pin
1 (Total) / 0 (Free) x FlexibleLOM
1 (Total) / 1 (Free) x Expansion Slot (x16 Mode)
1 (Total) / 1 (Free) x Expansion Slot (x8 Mode)
1 (Total) / 1 (Free) x microSDHC
Interfaces & Ports: 1 x Management – HP iLO – RJ-45
1 x Network – Ethernet 10GBASE-KR – RJ-45
